Example AD Lab

Example AD Lab#

This document describes the Active Directory lab built on VirtualBox, the machines, accounts, and the distinction between domain and local accounts.

Lab inventory#

Active Directory Lab

Active Directory Lab#

1. HYDRA-DC (Domain Controller)#

  • Hostname: HYDRA-DC

  • Role: Domain Controller for MARVEL.local

  • IP: 10.0.2.18 (static)

  • Important local account: vboxuser (VM user) — password P@$$w0rd! (local VM account)

  • Domain accounts present and used: MARVEL\\Administrator (password: windows), Domain Admin Tony Stark (tstark, password: Password1234!).

  • Service account: MARVEL\\SQLService (password: MYpassword123#) — used to run a service; an SPN was registered:

setspn -a HYDRA-DC/SQLService.MARVEL.local:60111 MARVEL\\SQLService
setspn -T MARVEL.local -Q "*/"

  • File share

    • SMB share name: hackme (hosted on HYDRA-DC)

Notes: As a DC there is no local SAM-based Administrator account in the same sense as a standalone Windows machine, administration is via domain accounts.

2. THEPUNISHER (Windows 10 Enterprise)#

  • Hostname: THEPUNISHER

  • Role: Domain-joined workstation

  • IP: 10.0.2.16 (static)

  • DNS: points to domain controller

  • Local VM account: vboxuser (password: windows1)

  • Domain accounts used to sign in: MARVEL\\administrator (password: windows)

  • Local Administrator enabled with password Password1!

  • Domain user fcastle is configured as a local administrator on this machine.

3. SPIDERMAN (Windows 10 Enterprise)#

  • Hostname: SPIDERMAN

  • Role: Domain-joined workstation

  • IP: 10.0.2.17 (static)

  • DNS: points to domain controller

  • Local VM account: vboxuser (password: windows2)

  • Domain accounts used to sign in: MARVEL\\administrator (password: windows)

  • Local Administrator enabled with password Password1!

  • Domain users fcastle and pparker are configured as local administrators on this machine.

Key concept: Domain accounts vs Local accounts#

  • Domain accounts

    • Authenticated by the domain (Active Directory). Credentials and groups are stored in AD and apply across domain-joined machines.

    • Identifiers commonly appear as DOMAIN\\user or user@domain.local.

    • Typically used for centralized administration, service accounts, and cross-machine permissions.

  • Local accounts

    • Stored in a machine’s local SAM database. Valid only on that specific machine (except when replicated manually).

    • Identifiers commonly appear as MACHINE_NAME\\user.

    • Useful for VM-specific tasks, boot-time access, or recovery when domain is unavailable.

Quick comparison#

Property

Domain Account

Local Account

Where authenticated

Domain controller (AD)

Local machine (SAM)

Scope

Any domain-joined machine (with appropriate rights)

Single machine only

Examples in this lab

MARVEL\\fcastle, MARVEL\\SQLService

vboxuser on each VM, local Administrator

How to tell account type during enumeration#

  • Domain accounts often appear as MARVEL\\user or user@MARVEL.local.

  • Local accounts appear as MACHINE_NAME\\user (e.g., THEPUNISHER\\Administrator) when enumerating local SAM or net user on that machine.

  • From a domain-joined machine, whoami /upn or echo %USERDOMAIN%\\%USERNAME% show domain-qualified names.

  • On the DC, user accounts are domain accounts, the DC does not use local SAM for user authentication.
